Mechanical Features 1.Specially designed mechanism,easily maintained,adjusted and dismantled. 2.Cotton web conducted by tri-decotton roller via special laddered roller with high speed. 3. Multi-pointed and continious concentrated absorbing structure. 4. Micro-electronic box and touching display with operations and relavant parameters displayed. 5.f100mm Feeding roller, lever type slidingmechanism,saparate transmission,V-F control accustomed to cotton feeding box wfih distributing equipment appended easilly appended easilly. 6.Fixed covers and cotton web cleaners set with 5 ahead and 5 ahead and 5 behind improve the cotton web quality effectively 7.Pre-distributing plate and adjustable de dust blade under the spur roller remove sundries effectively. 8.Reversable cover and doffing roller separate and collect cotton directly with high-speed smashing roller. 9.New cylinder and doffer design with high precision. 10.Cylinder motor started directly, steadily and smoothly. 11 .Dofer independent V-F transmission with synchronized arc belt brings firm and silent transmission for each running part. 12.The shelf structure designed as frame-box type with high stiffness and steady quality. 13.Speed inspecting aparatus plotted in many places monitor the status of rotating part respectively and time to ensure prodct quality. 1 .Chute feed 2.Suction point for under-card waste 3.Feed roller 4.Carding segment under licker-in 5.Licker-in 6.Suction point for licker-in 7.Suction point for flat fly 8.Apron Exit Suction Point(Both Sides) 9.Apron Back Suction Point(Both Sides) 10.Cylinder 11 .Flats 12.Transport the screen 13.Apron Entry Suction Point(Both Sides) 14.fixed lapfive front and five Back+suction Point for web cleaner 15.Doffer Triangle Suction Point 16.Doffer 17.Stripping roller 18.Suction point for cleaning roller 19.Web guider 20.Calender Roller 21 .Sliver 22.Coiler   Technical specifications: Working width:1020mm Applicable fiber length:22-76 coffon,chemical fiber or blend Production capacity(theorefical):80kg/set hour Hopper with:940mm Fixed quantily of coffon layer:400-800g/m Fixed quantily of sliver:3.5-6.5g/m Max sliver output speed:250m/min Weight of feeding pressure:40-60n/cm Diameter of feeding roller:f100mm Working diameter of cylinder-in:f1290mm Licker-in speed:808-1326r/min Working diameter of cylinder-in:f1290mm Cylinderspeed(optional):330r/min,360r/min,420r/min, 450r/min,500r/min Working number of laps/total number:32/86 Lap running speed:122-500mm/min Additional carding parts:licker-in sub-carding plate ,fixed lap(five front and five back) Working diameter of doffer:f706mm Doffer speed:6-70r/min Means of doffer speed variation:Frequency-controlled stepless Mode of card stripping:three-roller card stipping Times of drafting:68-300 Quantity of qir suctioner by the whole machine:4000m3/h negativepressuer>=1000pa Spot of dust suction of the whole machine:Centralized dust collection Application can specifications:f600×1000mm,f900×1100mm Form of shield:Totally enclosed driving power:Main motor 4kw doffer motor:1.1kw Feeding motor:0.55kw Crrd stripping cleaning roller motor:0.37kw Lap cleaning roller motor:0.55kw Land coverage:length4360×with2420mm(f600 sliver drier) Ner weight of machine:6000kg
